    DIN41612歐式插座 2X16P 母座 90度 R型

    • Type 3/R  Fmale

    SPECIFICATION

    MATERIAL

    Housing:PBT+30%G.F UL94V-O  Color:Champagne

    Contacts:Phosphor Bronze

    CONTACT PLATING

    Gold Plated on Contact Area,Tin Plated On Solder Tail,Ni Under Plated All Over.


    ELECTRICAL

    Current rating: 2 Amps .

    Contact resistance: 20 mΩ initial

    Insulation resistance: 1000 MΩ min @ 500 VDC

    Dielectric withstanding voltage: 1000 VAC / minute

    Operating temperature: -55°C TO +105°C
