Type 2/B
SPECIFICATION
MATERIAL
Housing:PBT+30%G.F UL94V-O COLOR:Champagne
Contacts:Brass
CONTACT PLATING
GOLD PLATED ON CONTACT AREA,TIN PLATED ON
SOLDER TAIL,Ni UNDER PLATED ALL OVER.
ELECTRICAL
Current rating: 2 Amps .
Contact resistance: 20 mΩ initial
Insulation resistance: 1000 MΩ min @ 500 VDC
Dielectric withstanding voltage: 1000 VAC / minute
Operating temperature: -55°C TO +125°C
